- Compatible systems per frequency band: 17 per 6 MHz TV channel, 22 per 8 MHz TV channel
- Auto Setup Features: Scan
- Audio Reference Companding: No
- Included Antennas: Detachable ½ wave antenna
- Antenna Options: Yes
- PC Control: Yes
- Receiver Network Ability: WWB6
- Rack Hardware: Included
- Transmitter Display: Backlit LCD
- Receiver Display: High-contrast LCD
- Battery, Endurance: 2 x AA Alkaline
- Environment: Musicians, Presenters, Houses of Worship, Education, Hotels and Conference Centers
Further Technical Specs
RF Carrier Range | 470–937.5 MHz, varies by region (See Frequency Range and Output Power table) |
Working Range | 100 m (328 ft) |
RF Tuning Step Size | 25 kHz, varies by region |
Image Rejection | >70 dB, typical |
RF Sensitivity | −97 dBm at 10−5 BER |
Latency | <2.9 ms |
Audio Frequency Response | QLXD1: 20 Hz – 20 kHz (±1 dB) |
Audio Dynamic Range | >120 dB, A-weighted, typical |
Total Harmonic Distortion | <0.1% |
System Audio Polarity | Positive pressure on microphone diaphragm produces positive voltage on pin 2 (with respect to pin 3 of XLR output) and the tip of the 6.35 mm (1/4-inch) output. |
Operating Temperature Range | -18°C (0°F) to 50°C (122°F) |
Storage Temperature Range | -29°C (-20°F) to 74°C (165°F) |
Transmission Type | Digital |
Tuning Bandwidth | 64 MHz* |
Compatible Systems per TV Channel | 17 per 6 MHz TV channel, 22 per 8 MHz TV channel |
Ethernet Networking | Yes |
WWB 6 Compatible | Yes |
Encryption | AES-256 |
Construction | All-metal hardware |
Rechargeable Batteries | Shure SB900 Lithium ion battery |
High Density Mode | No |
RF Output Level | Selectable 1/10 mW |
Antenna Bias | No, requires antenna distribution amplifier or UABIAST |
