SPX-900 (900W) > 파워앰프

제품특성

• 전면 LED Signal 표시기 - CLIP, SIGNAL, PROTECTOR, ACTIVE

• 보호회로 내장

• CLIP, LIMITER LED 표시기 내장

• 200 / 400 / 600 /900 / 1200 ​Watts 정격출력

• 후면 스위치로 간단하게 Mono parallel / Mono bridge / stereo 모드 변경

• 80mm 팬으로 자동 냉각

• XLR 병렬 입력 (1/4" * 2 + XLR Jack), 스피콘 + 바인딩포스트 터미널 출력 콘넥터

상세스펙

• 출력

4Ω, @1kHz, 1% THD

SPX-200 : 200 Watts (100W+100W)

SPX-400 : 400 Watts (200W+200W)

SPX-600 : 600 Watts (300W+300W)

SPX-900 : 900 Watts (450W+450W)

SPX-1200 : 1200 Watts (600W+600W)

• BRIDGE MODE POWER

8Ω, @1kHz, 1% THD

SPX-200 : 200 Watts

SPX-400 : 400 Watts

SPX-600 : 600 Watts

SPX-900 : 900 Watts

SPX-1200 : 1200 Watts

• Slew Rate

Stereo Mode, Each Channel : 100 Volts / us

Bridge Mode, Mono : 150 Volts / us

• 주파수 응답

±1dB , 1W RMS, 4Ω : 10Hz ~ 40 kHz

±1dB ,@ Rated output,4Ω : 20Hz ~ 20 kHz

• 왜율

20Hz-20kHz @ ratedOUTPUT POWER 8Ω : Less than 0.1%

• SMPTE IMD

@ Rated Output Power 8 Ω (60Hz & 7kHz) : Less than 0.1%

• 입력 임피던스

@ rated output poower 4Ω : 1V RMS (0dBm) 20 KΩ

• Damping Factor

8Ω, 1 kHz : Greater than 300

• 험 & 노이즈

Bellow Rated Output Power, 4Ω : 85dB (“A” Filter)

• 전력원

220-240VAC; 50/60Hz   (Supplied AC mains transformer depends on country requirements)

• Connector

Inputs : balanced connector (XLR type+1/4” TRS*2)

Outputs : Binding posts x 2, Speakon Terminal x 3

• 소비전력

@ Rated Output Power, 4Ω

SPX-200 : 330 Watts

SPX-400 : 670 Watts

SPX-600 : 970 Watts

SPX-900 : 1450 Watts

SPX-1200 : 1950 Watts

• 외형

SPX-200 : 483(W) x 103(H) x 320(D)

SPX-400 : 483(W) x 103(H) x 425(D)

SPX-600 : 483(W) x 103(H) x 425(D)

SPX-900 : 483(W) x 103(H) x 425(D)

SPX-1200 : 483(W) x 103(H) x 425(D)

• 중량

SPX-200 : 10.5 kg

SPX-400 : 13.5 kg

SPX-600 : 15.0 kg

SPX-900 : 16.0 kg

SPX-1200 : 18.5 kg
